Description
The DS223j is an efficient one-stop solution for all your data storage and sharing needs. With two bays of storage and Synology DiskStation Manager (DSM) on board, the DS223j allows you to create a private cloud to protect your files, share your data across several devices, store security footage with intelligent video surveillance tools, and more.
Main Specifications
|
Product Features
What’s in the box
|
   Extended Specification
General | |
---|---|
Device Type | NAS server |
Host Connectivity | Gigabit Ethernet |
Max Supported Capacity | 108 TB |
Width | 10 cm |
Depth | 22.55 cm |
Height | 16.5 cm |
Weight | 880 g () |
Processor / Memory | |
---|---|
Processors Installed | 1 x Realtek Semiconductor RTD1619B 1.7 GHz |
Number of Cores | Quad-Core |
Max Supported Qty | 1 |
RAM | 1 GB DDR4 |
Storage Controller | |
---|---|
Type | RAID |
Interface Type | SATA 6Gb/s |
RAID Level | RAID 0, RAID 1, JBOD |
Networking | |
---|---|
Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
Network / Transport Protocol | iSCSI, FTP, SMB, NFS, HTTP, HTTPs, SMB v2, SMB v3, CIFS |
Remote Management Protocol | SNMP, HTTP, HTTPS, LDAP |
Network Services Compatibility | Network File System (NFS), FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV), Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1) |
Performance | Maximum volume size:108 TB Maximum number of volume:64 Maximum concurrent connections:200 Local user account:1024 Local group account:256 Maximum number of shared folder:256 Maximum number of shared folders syncing tasks:4 Hybrid share folder number:5 Syslog:400 events per second |
Features | Hardware encryption, wake on LAN (WOL), Access Control List (ACL) support, VPN Server, B-tree file system (Btrfs), USB One Touch Copy, EXT4 file system, SSD trim, wake on WAN (WOW), NFS Kerberos authentication, cloud sync |
Compliant Standards | DLNA CERTIFIED |
Security DVR | |
---|---|
IP Cameras Supported | 12 |
Compression Format | H.264, H.265 |
Image Resolution | 1280×720, 1920×1080, 2048×1536, 2591×1944, 3840×2160 |
