Description
Companies are putting more network traffic and applications on their Ethernet infrastructure. For example, the increasing deployments of VoIP phones and IP cameras require more than simple Plug-and-Play connectivity. It needs the network intelligence to separate the voice and video traffic from data, and prioritize them accordingly. Additionally, Internet-based applications such as Hotmail and Google Calendaring have made keeping the network up a business-critical need. However, companies do not necessarily have more money or advanced training to deal with complex managed switches. The NETGEAR ProSAFE Plus switch meets this growing need by providing fundamental network features that will help optimize the performance of business networks. ProSAFE Plus switch also offers traffic monitoring for users to observe traffic behavior. If there are connectivity issues, these switches can identify and even locate connection problems via cable diagnostic test. To optimize traffic through the switches, ProSAFE Plus switch offers both port and tag-based prioritization to keep latency-sensitive trai c moving ahead of less critical packets. Also, ProSAFE Plus switch offers port and 802.1Q-based VLAN as a means of improving security and network performance.
Main Specifications
|
What’s in the box
|
   Extended Specification
General | |
---|---|
Device Type | Switch – 5 ports – unmanaged |
Enclosure Type | Desktop |
Subtype | Gigabit Ethernet |
Ports | 5 x 10/100/1000 |
Performance | Bandwidth:10 Gbps |
Capacity | Virtual interfaces (VLANs):64 Layer 2 multicast groups:128 |
MAC Address Table Size | 8K entries |
Jumbo Frame Support | 9KB |
Features | Trunking, VLAN support, IGMP snooping, DoS attack prevention, port mirroring, Weighted Round Robin (WRR) queuing, store and forward, Broadcast Storm Control, Weighted Random Early Detection (WRED), Quality of Service (QoS), fanless, DHCP client, Energy Efficient Ethernet, Strict Priority Queuing (SPQ), loop prevention |
Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3az |
Status Indicators | Port transmission speed, power, link/activity |
Expansion / Connectivity | |
---|---|
Interfaces | 5 x 1000Base-T RJ-45 |
Power | |
---|---|
Power Device | External power adapter |
Miscellaneous | |
---|---|
Compliant Standards | C-Tick, CISPR 22 Class B, UL 1950, EN50082-1, EN55022 Class B, FCC Part 15 B, EN55024 Class B, CCC Class B, VCCI Class B |
Localisation | United Kingdom |
Dimensions & Weight | |
---|---|
Width | 9.4 cm |
Depth | 10.1 cm |
Height | 2.6 cm |
Weight | 0.27 kg |
Manufacturer Warranty | |
---|---|
Service & Support | Limited warranty – lifetime Limited warranty – power supply – 2 years |
Environmental Parameters | |
---|---|
Min Operating Temperature | 0 °C |
Max Operating Temperature | 50 °C |
Min Storage Temperature | -20 °C |
Max Storage Temperature | 70 °C |
