HPE Aruba Instant On 1930 48G 4SFP/SFP+ Switch

HPE Aruba Instant On 1930 48G 4SFPSFP+ Switch
HPE Aruba Instant On 1930 48G 4SFPSFP+ Switch
HPE Aruba Instant On 1930 48G 4SFPSFP+ Switch
HPE Aruba Instant On 1930 48G 4SFPSFP+ Switch

£250.08

Login To See Pricing

HPE Aruba Instant On 1930 48G 4SFP/SFP+ Switch

HPE Aruba Instant On 1930 48G 4SFP/SFP+ Switch

LEASE ME
Categories , Tags , , , ,

Description

Advanced, smart-managed, fixed-configuration Gigabit switches designed for small businesses. Easy-to-deploy, secure and affordable. The first switches with Instant On “anywhere, anytime” configuration and management. Using the Instant On mobile app or the cloud-based web portal, quickly setup, monitor and manage the 1930 switch. Can also choose to manage the device through the local web GUI. This model has 48 10/100/1000 RJ-45 and 4 SFP 1/10GbE ports.

Main Specifications

Product Description HPE Aruba Instant On 1930 48G 4SFP/SFP+ Switch – switch – 48 ports – Managed – rack-mountable
Device Type Switch – 48 ports – L2+ – Managed
Enclosure Type Rack-mountable 1U
Subtype 10 Gigabit Ethernet
Ports 48 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+
Performance Throughput:130.95 Mpps ¦ Switching capacity:176 Gbps ¦ Latency (1 Gbps):2.2 µs ¦ Latency (10 Gbps):1.2 µs
Capacity Routing table entries (static):32
MAC Address Table Size 16K entries
Jumbo Frame Support 9216 bytes
Routing Protocol IGMPv2, IGMP, static IPv4 routing, MSTP, RSTP, STP
Remote Management Protocol SNMP, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SCP, DHCP, IPv4, IPv6
Features Flow control, DHCP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, manageable, IPv6 support, half duplex mode, full duplex mode, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, Trusted Platform Module (TPM), IPv4 support, LACP support, LLDP support, Link Aggregation Control Protocol (LACP), Class of Service (CoS), SNMP support, 1.5MB packet buffer, Bridge protocol data unit (BPDU), LLDP-MED, Energy-Efficient Ethernet (EEE)
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az
Power AC 120/230 V (50/60 Hz)
Dimensions (WxDxH) 44.25 cm x 28.24 cm x 4.39 cm
Weight 3.13 kg
Localisation English / United Kingdom
Manufacturer Warranty Limited lifetime warranty



   Extended Specification

General
Device Type Switch – 48 ports – L2+ – Managed
Enclosure Type Rack-mountable 1U
Subtype 10 Gigabit Ethernet
Ports 48 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+
Performance Throughput:130.95 Mpps
Switching capacity:176 Gbps
Latency (1 Gbps):2.2 µs
Latency (10 Gbps):1.2 µs
Capacity Routing table entries (static):32
MAC Address Table Size 16K entries
Jumbo Frame Support 9216 bytes
Routing Protocol IGMPv2, IGMP, static IPv4 routing, MSTP, RSTP, STP
Remote Management Protocol SNMP, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SCP, DHCP, IPv4, IPv6
Encryption Algorithm SSL
Authentication Method RADIUS
Features Flow control, DHCP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, manageable, IPv6 support, half duplex mode, full duplex mode, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, Trusted Platform Module (TPM), IPv4 support, LACP support, LLDP support, Link Aggregation Control Protocol (LACP), Class of Service (CoS), SNMP support, 1.5MB packet buffer, Bridge protocol data unit (BPDU), LLDP-MED, Energy-Efficient Ethernet (EEE)
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az
Processor 1 x ARM Cortex-A9:800 MHz
RAM 512 MB
Flash Memory 256 MB
Expansion / Connectivity
Interfaces 48 x 1000Base-T RJ-45
4 x Gigabit / 10Gbit LAN SFP+
Power
Power Device Internal power supply
Voltage Required AC 120/230 V (50/60 Hz)
Miscellaneous
MTBF 114 years
Compliant Standards VCCI, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, CNS 13438, EN 55024:2010, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, IEC 62368-1, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368-1:2014, CAN/CSA-C22.2 No. 60950-1, CISPR 35, EN 55035:2017, EN 55032:2015+AC:2016 Class A
Localisation English / United Kingdom
Dimensions & Weight
Width 44.25 cm
Depth 28.24 cm
Height 4.39 cm
Weight 3.13 kg
Manufacturer Warranty
Service & Support Limited warranty – lifetime
Technical support – phone consulting – 90 days
Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Humidity Range Operating 15 – 95% (non-condensing)
Min Storage Temperature -40 °C
Max Storage Temperature 70 °C
Humidity Range Storage 15 – 95% (non-condensing)

Aruba Instant On 1930 48G 4SFP/SFP+ Switch

The Aruba Instant On 1930 switch series is designed for small and growing businesses that require enhanced performance to support bandwidth-demanding applications. The Aruba Instant On 1930 switch series seamlessly integrates with existing Instant On indoor/outdoor access points and can be centrally managed with the Instant On mobile app onsite or remotely. These cloud-managed layer 2+ Ethernet switches consist of 8-, 24-, and 48-port Class 4 PoE (i.e. PoE+) and non-PoE Gigabit Ethernet models, with 1G SFP slots on 8-port model and 1G/10G SFP+ slots on 24-/48G models for fiber connectivity.
Aruba Instant On 1930 48G 4SFP/SFP+ Switch
Seven advanced smart managed Layer 2+ Gigabit switches for high-performance connectivity.
Non-PoE and Class 4 PoE (i.e. PoE+) 8-, 24- and 48-port models for deployment flexibility.
1G/10G SFP+ ports on 24-and 48-port models for fiber connectivity.
Aruba Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.
Option to manage your switches through local web GUI.
Limited Lifetime Warranty.
Simplify Network Deployment and Management for Small Organizations

Simplify Network Deployment and Management for Small Organizations

  • The Aruba Instant On 1930 switch series features easy-to-use, out-of-the-box, plug-and-play deployment.
  • The series offers a complete portfolio of choices for increased small business flexibility. It consists of seven models including 8G-, 24G-, and 48G-ports with and without class 4 PoE (i.e. PoE+).
  • The 24- and 48- port models include four SFP/SFP+ transceiver slots that support Gigabit or 10-Gigabit speeds for fiber connectivity.
  • The Aruba Instant On 1930 switch series can be deployed using two management modes – Instant On cloud-management (access via mobile app and/or web portal) and the local web GUI.
Keep Your Business Protected with Integrated Security Features

Keep Your Business Protected with Integrated Security Features

  • The Aruba Instant On 1930 switch series supports energy efficient Ethernet for lower power consumption and an enhanced feature set for more robust operation.
  • Enhanced security features such as IEEE 802.1x, and VLANs guard your network from unwanted or unauthorized access.
  • Automatic denial-of-service (DOS) monitors and protects the network against malicious attacks.
  • Management security restricts access to critical configuration commands, offers multiple privilege levels with password protection.
Deliver High Perfomance

Deliver High Perfomance

  • The Aruba Instant On 1930 switch series delivers advanced functionalities including customizable like VLANs, link aggregation, Spanning Tree Protocols, and IEEE 802.1X access control.
  • 8-, 24-, and 48-port configurations with a choice of non-PoE and Class 4 PoE models provides deployment flexibility that fits all small business environment. Class4 PoE options allow to power devices like IP phones, surveillance cameras and access points, without the cost of additional cabling.
  • The 24- and 48-port models include 1G/10G SFP+ ports for reliable fiber connectivity and other connections across longer distances.
  • The switch series is covered by the Limited Lifetime Warranty with 24×7 phone support for 90 days and chat support for the entire warranty duration
