Description
Main Specifications
|
|
Extended Specification
General | |
---|---|
Type | Personal computer |
Product Form Factor | Small form factor |
Sensors | HP Tamper Lock |
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
Localisation | Language:English / region:United Kingdom |
Bundled with | HP Wolf Pro Security Edition (3 years) |
Processor / Chipset | |
---|---|
CPU | Intel Core i7 (13th Gen) 13700 |
Clock Speed | 2.1 GHz (P-core) / 1.5 GHz (E-core) |
Max Turbo Speed | 5.2 GHz (P-core) / 4.1 GHz (E-core) |
Number of Cores | 16-core |
CPU Qty | 1 |
Max CPU Qty | 1 |
L2 cache | 24 MB |
CPU Upgradability | Upgradable |
Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0 |
Chipset Type | Intel Q670 |
Cache Memory | |
---|---|
Installed Size | L3 Cache – 30 MB |
Cache Per Processor | 30 MB |
RAM | |
---|---|
Installed Size | 16 GB / 64 GB (max) |
Technology | DDR4 SDRAM – non-ECC |
Effective Memory Speed | 3200 MHz |
Rated Memory Speed | 3200 MHz |
Form Factor | DIMM 288-pin |
Slots | 2 (Total) / 1 (empty) |
Features | Unbuffered |
Configuration Features | 1 x 16 GB |
Hard Drive | |
---|---|
Type | SSD – M.2 2280 |
Capacity | 1 x 512 GB |
Interface Type | PCI Express |
Features | NVM Express (NVMe) |
Storage Controller | |
---|---|
Type | 1 x SATA |
Channel Qty | 3 |
Optical Storage | |
---|---|
Type | No optical drive |
Monitor | |
---|---|
Monitor Type | None. |
Graphics Controller | |
---|---|
Graphics Processor | Intel UHD Graphics 770 Dynamic Video Memory Technology |
Video Interfaces | HDMI, DisplayPort |
HDCP Compatible | Yes |
Audio Output | |
---|---|
Sound Output Mode | Stereo |
Max Sampling Rate | 192 kHz |
Compliant Standards | High Definition Audio |
Input Device | |
---|---|
Type | Mouse, keyboard |
Keyboard | |
---|---|
Keyboard Name | HP 320K |
Interface | USB |
Localization & Layout | UK |
Mouse | |
---|---|
Mouse Name | HP 125 |
Networking | |
---|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Remote Management Protocol | SNMP 2 |
Features | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az |
Expansion / Connectivity | |
---|---|
Bays | 1 (total) / 1 (free) x external 5.25″ Slim Line 1 (total) / 1 (free) x internal 3.5″ |
Slots | 1 (total) / 1 (free) x PCIe 4.0 x16 1 (total) / 1 (free) x PCIe 4.0 x1 1 (total) / 1 (free) x M.2 Card – 2230 (PCIe x1 mode (for wireless module)) 1 (total) / 0 (free) x M.2 Card – 2280 (PCIe x4 mode (for internal storage)) |
Interfaces | 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) 3 x USB 3.2 Gen 2 (3 in front) 1 x USB-C 3.2 Gen 2 (1 in front) 1 x audio line-out/line-in 1 x DisplayPort 1.4a 1 x HDMI 2 x USB 2.0 (wake functionality) 3 x USB 3.2 Gen 1 1 x LAN (Gigabit Ethernet) |
Miscellaneous | |
---|---|
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop, integrated accessories cable lock |
Security Slot Type | Kensington security slot / HP Business PC Security Lock slot |
Compliant Standards | FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, WEEE, KCC Class B, Common Criteria EAL4+, VCCI Class B, low halogen, CAN/CSA-C22.2 No. 62368-1, UL 62368-1, IEEE 1680.1-2018 |
Power | |
---|---|
Device Type | Power supply |
Voltage Required | AC 90-264 V (50/60 Hz) |
Power Factor Correction | Yes (active) |
Operating System / Software | |
---|---|
OS Provided | Windows 11 Pro English |
Software | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Client Catalogue (free download), HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP Client Management Script Library (free download), HP BIOSphere Gen6, myHP, Touchpoint Customiser for Commercial, HP Desktop Support Utilities, HP Tamper Lock, HP Image Assistant Gen5 (free download), HP SureStart Gen7, HP Easy Clean, HP Smart Support, HP Manageability Integration Kit (free download), HP Patch Assistant (free download) |
Sustainability Information | |
---|---|
ENERGY STAR Certified | Yes |
Manufacturer Warranty | |
---|---|
Service & Support | Limited warranty – parts and labour – 1 year – on-site |
Dimensions & Weight | |
---|---|
Width | 27 cm |
Depth | 30.8 cm |
Height | 9.5 cm |
Weight | 4.2 kg |
Dimensions & Weight (Shipping) | |
---|---|
Shipping Width | 39.4 cm |
Shipping Depth | 49.9 cm |
Shipping Height | 20.5 cm |
Shipping Weight | 7.25 kg |
Environmental Parameters | |
---|---|
Min Operating Temperature | 10 °C |
Max Operating Temperature | 35 °C |
Humidity Range Operating | 10 – 90% RH (non-condensing) |
Windows 11
Work anywhere without compromising on performance or security with Windows 11 powered by HP’s collaboration and connectivity technology.
Security is your top priority
The HP Wolf Pro Security Edition provides preconfigured enterprise-level PC protection for small and medium sized businesses.
BIOS management over the network
HP Sure Admin, a modern BIOS management tool, eliminates the need for a password or BIOS configuration utility in the OS by creating a digital signature that allows IT administrators to securely manage BIOS settings over a network.
Browse confidently
Help protect your PC from websites and read only Microsoft Office and PDF attachments with embedded malware, ransomware, or viruses with hardware-enforced security from HP Sure Click.
Automatic recovery from firmware attacks
Firmware attacks can completely devastate your PC. Stay protected with HP’s self-healing BIOS – HP Sure Start Gen7 automatically recovers the BIOS from malware, rootkits, or corruption.
HP Sure Sense
Malware is evolving rapidly and traditional antivirus can’t always recognize new attacks. Protect your PC against never-before-seen attacks with HP Sure Sense, which uses deep learning AI to provide exceptional protection against advanced malware.
Processor
Intel® Core™ i7 13700
Graphics
Intel® UHD Graphics 770
Memory
16 GB DDR4
Operating System
Windows 11 Pro
Hard drives
512 GB SSD
Dimensions
27 x 9.5 x 30.8 cm
Ports
1 headphone/microphone combo
1 SuperSpeed USB Type-C® 10Gbps signaling rate
3 SuperSpeed USB Type-A 10Gbps signaling rate
1 audio-out
1 power connector
1 RJ-45
1 HDMI 1.4
3 SuperSpeed USB Type-A 5Gbps signaling rate
1 DisplayPort™ 1.4
2 USB Type-A 480Mbps signaling rate
