Description
The PowerEdge T550, powered by Intel Xeon Silver processor, offers advanced technologies such as accelerators to address data-intensive workloads outside the traditional data center.
Main Specifications
|
Product Features
|
Extended Specification
General | |
---|---|
Type | Server |
Bundled Services | 3 Years Basic Onsite |
Product Form Factor | Tower |
Server Scalability | 2-way |
Hot-Swap Bays Qty | 8 |
Colour | Black |
Processor / Chipset | |
---|---|
CPU | Intel Xeon Silver 4309Y |
Clock Speed | 2.8 GHz |
Max Turbo Speed | 3.6 GHz |
Number of Cores | 8-core |
CPU Qty | 2 |
Max CPU Qty | 2 |
CPU Upgradability | Upgradable |
Cache Memory | |
---|---|
Installed Size | 24 MB |
Cache Per Processor | 12 MB |
RAM | |
---|---|
Installed Size | 64 GB |
Technology | DDR4 SDRAM |
Effective Memory Speed | 2666 MHz |
Rated Memory Speed | 3200 MHz |
Form Factor | DIMM 288-pin |
Slots | 16 (Total) / 14 (empty) |
Features | Registered, dual rank |
Configuration Features | 2 x 32 GB |
Hard Drive | |
---|---|
Type | SSD – hot-swap – 2.5″ |
Capacity | 1 x 480 GB |
Interface Type | SATA 6Gb/s |
Features | 1 DWPD, Read Intensive, advanced format 512 |
Storage Controller | |
---|---|
Type | 1 x RAID |
Storage Controller Name | PERC H755 Front |
Optical Storage | |
---|---|
Type | No optical drive |
Monitor | |
---|---|
Monitor Type | None. |
Graphics Controller | |
---|---|
Graphics Processor | Matrox G200 |
Video Memory | 16 MB |
Video Interfaces | VGA |
Networking | |
---|---|
Ethernet Ports | 2 x Gigabit Ethernet |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Remote Management Controller | Integrated Dell Remote Access Controller 9 Enterprise 15G (iDRAC9 15G) |
Expansion / Connectivity | |
---|---|
Bays | 8 (total) / 7 (free) x hot-swap 3.5″ |
Interfaces | 2 x USB 2.0 (1 front, 1 rear) 2 x LAN (Gigabit Ethernet) 1 x management (iDRAC dedicated port) 1 x VGA (1 rear) 2 x USB 3.0 (1 front, 1 rear) |
Miscellaneous | |
---|---|
Included Accessories | Bezel, riser card |
Power | |
---|---|
Device Type | Power supply – hot-plug |
Power Redundancy | Yes |
Power Redundancy Scheme | 1+1 (with optional power supply) |
Installed Qty | 1 |
Max Supported Qty | 2 |
Power Provided | 1100 Watt |
80 PLUS Certification | 80 PLUS Titanium |
Dimensions & Weight | |
---|---|
Width | 20 cm |
Depth | 68.05 cm |
Height | 45.9 cm |
Weight | 44.48 kg |
Your Innovation Engine
The PowerEdge T550, powered by 3rd Generation Intel® Xeon® Scalable processors, offers advanced technologies such as accelerators to address data-intensive workloads outside the traditional data center.
Expandable tower server for enterprise workloads outside the data center
The PowerEdge T550, powered by 3rd Generation Intel® Xeon® Scalable processors, is designed to address data-intensive workloads.
- New chassis design offers higher performance technologies in a quieter, more management-friendly enclosure
- Ideal for traditional corporate IT, virtualization, databases and analytics, and AI/ML and inferencing
- Enterprise-class tower chassis that provides ease of management and expandability for growth and performance
Systems Management and Security Solutions
OpenManage systems management
The Dell OpenManage systems management portfolio helps tame the complexity of your IT environment with tools and solutions to discover, monitor, manage, update, and deploy your PowerEdge infrastructure.
Intelligent Automation
PowerEdge and OpenManage solutions integrate tools across the portfolio to help organizations automate the server lifecycle, optimize operations, and scale efficiently.
Built-in security
Dell PowerEdge servers are made with a cyber resilient architecture that builds in security at every phase of the product lifecycle, from the silicon root of trust and secured component verification, to signed firmware and drift detection, to BIOS recovery.
