Description
Attach the device to an emergency power off (EPO) system so that power can be turned off in an emergency situation. Green mode bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. High frequency design reduces or eliminates bulky transformers resulting in lighter units for ease of handling. Energy meter provides actual kilowatt hours of usage for energy conscious users. Intuitive LCD interface provides clear and accurate information with the ability to configure the UPS locally with easy to use navigation keys. UPS recognizes when external battery packs are attached and automatically adjusts runtime. Multiple outlet groups may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on / off and non-critical load shedding.
Main Specifications
|
Product Features
|
   Extended Specification
General | |
---|---|
Device Type | UPS – rack-mountable |
Height (Rack Units) | 2U |
Colour | Black |
Power Device | |
---|---|
UPS Technology | Line interactive |
Power Modules Qty | 1 |
Input Voltage | AC 230 V |
Frequency Provided | 47 – 63 Hz |
Frequency Required | 50/60 Hz |
Input Connectors | Power IEC 60320 C14 |
Power Output Connectors Details | 8 x power IEC 60320 C13 |
Output Voltage | AC 230 V ± 5% – 47 – 63 Hz |
Power Capacity | 600 Watt / 750 VA |
Output Waveform | Sinewave |
Surge Suppression | Yes |
Surge Energy Rating | 645 Joules |
Battery | |
---|---|
Technology | Lead Acid |
Run Time (Up To) | 14.2 min at full load 37.8 min at half load |
Recharge Time | 3 hours |
Expansion / Connectivity | |
---|---|
Expansion Slots | 1 (total) / 1 (free) x SmartSlot |
Miscellaneous | |
---|---|
Cables Included | Serial cable – external Power cable – integrated – 1.8 m |
Features | Audible alarm, LCD display |
Compliant Standards | C-Tick, UL 1449, VDE, EN 50091-2, RoHS Exemption 7b, EN 50091-1 |
Software / System Requirements | |
---|---|
Software Included | APC PowerChute Business Edition |
Manufacturer Warranty | |
---|---|
Service & Support | Limited warranty – 3 years Limited warranty – batteries – 2 years |
Environmental Parameters | |
---|---|
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 0 – 95% |
Sound Emission | 40 dBA |
Dimensions & Weight | |
---|---|
Width | 8.9 cm |
Depth | 49 cm |
Height | 43.2 cm |
Weight | 22.1 kg |
Dimensions & Weight (Shipping) | |
---|---|
Shipping Width | 24.6 cm |
Shipping Depth | 62 cm |
Shipping Height | 58.9 cm |
Shipping Weight | 26.5 kg |
